Device Type
Chemical Spraying Drone
Symmetry Axis
2280 mm
Unfolded Dimensions
1783 mm x 1783 mm x 790 mm
Folded Dimensions
950 mm x 912 mm x 918 mm
Weight (including battery)
48 kg
Standard Take-off Weight
98 kg
Maximum Flight Speed
13 m/s
Spraying Width
8-1 m
Propeller Size
56 inches
Battery
18S 30000 mAh
Battery Weight
15 kg +/- 300 g
Operating Voltage
67.5-70.2 V (18S)
Charging Time
15-25 minutes
Charging Cycles
300-500 times
Payload Capacity
50 kg
Spraying Rate
Max 16 L/min
Hovering Time at Full Load
9 minutes
Flight Time
Without Load: 15-25 minutes With Full Load: 8-12 minutes
Work Efficiency
1-3 mu/min
Packaging Box Dimensions
110 cm x 100 cm x 100 cm
Ground Station
Android and PC with voice guidance
Route Planning Support
Fully autonomous operation, support for A and B point navigation
Automatic Take-off and Landing
Enhances safety
Resume Spraying
From the point of stop
Chemical Level Monitoring
Automatic return if chemical is low
Battery Level Monitoring
Automatic return at low battery
Microwave Altimeter Radar
Stable altitude, support for terrain-following flights
Safety Features
Geofencing, logging function, landing lock, restricted zones
Vibration and Signal Loss Protection
Increased reliability
Video Recording Function
Real-time image transmission
Dual Pump Mode
Flexibility in spraying
Collision Avoidance
Obstacle detection and avoidance
Fully Assembled ARF X13 Motor + K++v2
Water Pump
18S 8L * 2
Centrifugal Nozzles
4 pcs
Remote Control
H12
Altimeter Radar
For enhanced accuracy
Collision Avoidance Radar
CAN HUB Module
Wooden Case
For easy transport
Battery
18S 30000 mAh
Smart Charger
18S 7000W
